Which option on the Cisco Telepresence System administration WebGUI allows selecting table type?

Troubleshooting --> Hardware Setup -> Configuration
Troubleshooting -> Hardware Setup --> Camera
Troubleshooting -> Hardware Setup -> Other Devices

Which statement is correct when tuning the cameras by using the WebGUI of the Cisco TelePresence codec?

If the room uses outside lighting, click the Disable radio button for the Camera Auto Brightness and Camera
Auto Color Balance choices.
Auto Color Balance can produce the best results when the colors of the walls in your room are white or gray.
If the user is 4 to 5 feet (1.2 to 1.5 m) away from the display, click the 4 feet radio button for the Focus
Distance radio choice. If the user is farther than 5 feet (1.5 m) away, click the 6 feet choice.

Identify the port number where the Audio Video expansion box should connect.

Identify the port number where the Audio Video expansion box should connect.
12
13
10

A Cisco Telepresence System 1000 is being installed into a room where the walls are constructed of drywall
over metal studs. What is the correct mounting hardware for this type of installation?

5/16 x 5-inch wood screws
M6 0 x 80-mm hex head screws
1/4-20 Snap Toggler BB anchor

Which would be considered the best environment to house a dedicated Cisco TelePresence system?

a conference room next to the elevator for easy accessibility
a large meeting room used for events
a conference room along an interior corridor

Which two statements describe the design goals for the Cisco Telepresence system?
(Choose two)

Select the two correct answers
Creating a uniform feeling across all installations helps to create the illusion of participants being in the same
room
Customers should use different colors in each of the Cisco Telepresence rooms to help identify the different
locations
Repeatability strengthens the feeling of a common, seamless environment, which enhances the overall
experience

Which statement is correct when discussing the Cisco TelePresence System 1300?

The system is designed to support meetings of six to eight participants
Voice-enabled switching is performed by the codec to select the active speaker in the room and capture the
video for the remote side
he power and Ethernet outlets must be positioned directly behind the unit

The customer decides to use static IP addressing for the codec. Which parameters must be configured?

Select the three correct answers
IP address
gateway IP address
IP address subnet mask

Which two statements are correct when calibrating the Cisco Telepresence cameras?
(Choose two)

Select the two correct answers
If the Auto Adjust test to automatically adjust lighting and color balance fails, you may need to add more light
If the room uses fixed artificial lighting, click the Disable radio button fur the Camera Auto Brightness and
Camera Auto Color Balance
If the room uses outside lighting, click the Disable radio button for the Camera Auto Brightness and Camera
Auto Color Balance

Which statements are correct when tuning the camera on a Cisco TelePresence CTS-1xxx system?

Select the three correct answers
Target placement should match the green and red boxes on the screen, respectively
Place the large target five feet behind the small target
Tune the camera so that the red and green bars line up as closely as possible

What are the two choices for focal distance on a CTS-500? (Choose two)

Select the two correct answers
6 ft (1.83 m)
8.5 ft (2.59 m)
4 ft (1.22 m)

After connecting to a codec via WebGUI, you are prompted for a username and password. Which username/password combination is used on the codec by default?

admin, Cisco
admin, cisco
Cisco, Cisco

When using HFR codec in a multipoint call, what happens when an endpoint without HFR calls in?

The call drops since there are different frame rates
The entire call downgrades the data channel to 5 fps but when the endpoint without HFR codec drops, it
automatically increases the data channel to 30 fps
The entire call downgrades the data channel to 5 fps

What is the default configuration for displaying presentations on a Cisco Telepresence System 1000?

Presentations are displayed as presentation-in-picture
Presentations are displayed on an external display and include a presentation codec.
A projector and screen are used to display presentations.

During your RRA assessment of a potential Cisco TelePresence System 1300 room you notice:
; The HVAC diffuser has noticeable noise (measured at48 1dB) which sounds like rushing air
What three recommendations should be made to the customer?

Select the three correct answers
The customer should contact an HVAC specialist to review and recommend an appropriate solution
The customer should replace the diffusers with a diffuser that is rated with a noise criterion of 10 or greater
The customer should replace the ducting directly above the room with acoustically treated ducting to remove
the sound of rushing airflow

Which two statements are correct when discussing light measurement recommendations for a Cisco
Telepresence System 1100 room? (Choose two)

Select the two correct answers
When measuring overall illumination in the room, the light range should be between 250 and 800 lux
The overall illumination target with the auto features disabled is between 250 and 460 lux
Overall illumination should be measured with the light sensor pointed at the ceiling

What are two Cisco recommendations when a customer has magnetic ballast installed in a Cisco TelePresence
room? (Choose two.)

Select the two correct answers
Enable 50-Hz flicker reduction
Enable focus distance to 4 feet
Replace the light fixture with an electronics fixture

During your assessment of a potential Cisco TelePresence System 1300 room, you notice:
; The ceiling is 8 feel (2 4meters) high and currently illuminated with recessed parabolic light fixtures.
Which lighting recommendation is the most appropriate?

The ceiling should be raised higher than 8 feet (2.4 meters) to accommodate appropriate light fixtures for use
with Telepresence
The existing fixtures are not ideal but are adequate for use with TelePresence
The existing fixtures should be replaced with recessed indirect light textures

Which is a design requirement for Cisco Telepresence room aesthetics?

Every room should be identical.
Maintain continuity in appearance among rooms
The only wall treatment should be paint

Which statement is correct when discussing the microphone placement for the Cisco TelePresence System
1000?

Attach the microphone to the table by peeling the backing off the bottom of the microphone base and stick
the microphone to the alignment guide.
You can install the second microphone on the opposite side of the table to provide full-table microphone
coverage for audio-only conferences.
Place the microphone on the table approximately 18 inches (46 centimeters) forward of where the
participants will sit.

In the Cisco TelePresence administration WebGUI, the camera Auto Adjust can be used to check which
setting?

life size
white color balance
HDMI input threshold

What is the leveling process for the Cisco TelePresence System 1000 frame?

Place a level on the middle and upper crossbars and adjust the feet as necessary to ensure that the frame is
horizontally level
Place a level on the side of the frame and adjust the feet as necessary to ensure that the frame is vertically
level
With only one display, there is no need to level the frame before attaching it to the wall

Which two statements about the Cisco TelePresence codec software upgrade process are true? (Choose two.)

Select the two correct answers
The peripherals upgrade can take up to 60 minutes to complete. Do not manually reboot the codec during
the peripherals upgrade
To abort the upgrade, you can reboot the codec manually before the codec finishes downloading the
software image.
Cisco TelePresence codecs must have IP address information for the TFTP servers that the Cisco Unified
Communications Manager uses.

The Cisco TelePresence System 1100 and Cisco TelePresence System 1300 mounting brackets has limited
side-to-side adjustability. What is the first thing to consider before you mount the bracket?

Measure the correct width between the drill holes of the mounting bracket.
Verify with the customer where the conference table will be located, find the center of the conference table,
and then find the corresponding point on the mounting wall.
Level the bracket.

When using Auto-Collaborate, what two actions need to be done to display the laptop content after connecting
the cable? (Choose two.)

Select the two correct answers
Press the Auto-Collaborate softkey
Set the laptop resolution to 1024x768
Use function key on the laptop to send signal to external display
